LECAI Deluxejet16W Eco solvent printer

date :2017-8-17 23:18:45hits :1830author:郑州乐彩


PRODUCT FEATURE:

1、Intelligent paper detection system.It can prevent cocking the paper,Automatically suspended,Avoid scratching the print head;Stop printing when the paper runs out.

2、Humanized ink vehicle with"high/middle/low"three gears.According to the print material thickness, convenient and quick switch.

3、Intelligent heating system.If printing stop,close by itself,Ensure security and picture is undamaged when it is unattended.

4、High-speed silent guide rail and bearings.Adopt japanese TCK guide rail,Double sliders and imported bearings,Ensure the printing of high-speed, smooth, accurate, quiet.

5、Wire standardization。Stable、Higer reliability.The wires twine together to avoid electromagnetic interference.


Specification





Model

Deluxejet16W




Print technology






Printhead Type
Epson 5113




Printhead Number
Two




Print   Resolution
Bir-direction   cleaning,Flash,Moisturized

Printhead height
2-3mm




Cleaning

Automatically cleaning   Flash,Moisturized

Print speed






Production   4pass
57.4㎡/h




Precision   6pass
44.8㎡/h




High quality   8pass
31.2㎡/h




Ink system






Type

Water based ink
Color

Four color (C/M/Y/K)


Ink tank   capacity
1500ml/Color



Supply

Positive pressure CISS Bulk   ink

Media







Printing width
1650mm




Types
photopaper,Reflecting   materials,PP,Sublimation paper
Max weight
40Kg




Disposition






Take up system
Standard




Heating system
Front heating   controlled by smart board



Extermal Dryer
Synchronous dry fans


Operation







Language

English/Chinese



PC System

Windows



Environment
Temperature:18-25℃   Humidity:35-65%RH
Printing







Interface

USB



RIP

Maintop/Photoprint/Wasatch


Other







Power supply
AC-220V,50Hz/60Hz


Power(W)

Min:32W,Max:1500W


Noises

Min<32dp;Max<65dp


Machine size(LxWxH)2725mm*545mm*1400mm(L*W*H)

N.W(kg)

200kg




Packing   size(LxWxH)  2855mm*825mm*620mm(L*W*H)

G.W(kg)

260kg








  Zhengzhou Locor Technology Co., Ltd. has a registered capital of 26 million RMB. The company has a young, efficient, united and innovative elite team, and an entrepreneurial environment that catches up with the international advanced level, leads the development of the Chinese industry.

 Locor pays attention to the research and application development of independent technology in the field of printing equipment,has established a company technology research and development center, equipped with advanced equipment and testing instruments with a good R&D experimental environment. The company's technical department cooperates with many research institutes at home and abroad, uses the current new micro-electromechanical and micro-electronic technology to conduct exploratory research and development. It is used in printer print head drive analysis, rack manufacturing, testing, control system design, trial production, etc. Unique insights and innovative inventions.

    Locor has applied for 51 patents related to digital printing equipment, including 3 invention patents; in 2008, the company was recognized as a high-tech enterprise by Henan Science and Technology Department, has passed the EU CE certification in 2008; in May 2010, Zhengzhou Development and Reform Commission Approved the establishment of Zhengzhou Digital Wide-format Printing Equipment Engineering Research Center and listed it in the National Twelfth Five-Year Plan for Electronic Information Industry; In June 2010, it officially started the shareholding system reform and became the first batch of new three-board enterprises in Zhengzhou High-tech Industrial Development Zone.

At present, Locorproducts and service organizations have covered more than 80 countries and regions in 31 provinces and cities in China and overseas; Locor are willing to work together with friends in the industry to provide satisfactory products and services for domestic and foreign customers!
